2U Rackmount Chassis EJ-2U205-C Product Descriptions
The 2U Rackmount Chassis EJ-2U205-C offers great expand-ability and cooling capacity for your server computer. It supports a 12″ x 13″ EATX and smaller form factor motherboard. The EJ-2U205-C also features a quality fan filter and 3 x 80mm cooling fan for optimum ventilation of the system.
| Standard | EIA RS-310C 19″ Rackmount Standard |
|---|---|
| Construction | Heavy Duty Cold Rolled Electroplated Steel |
| Color | Black (Standard) |
| System Boards | Pentium 4, Dual Xeon, AMD 64, Dual Opteron |
| Motherboard Size | Support EATX M/B (Max. to 12″ x 13″) |
| Drive Bays | 1 x 5.25″ Slim CDROM Bay, 1 x 3.5″Open, 3 x 3.5″Hidden |
| Power Supply | (Rear Chassis Installation) 2U Single (up to 700Watt) or 2U Redundant Power (up to 600Watts)(Optional) Max Depth 300mm |
| Cooling Units | 3 x (80mm = 42.5CFM ea.) Ball Bearing Fan plus 1 x Rear Exhaust Blower Fan (Optional) |
| Expansion Slot | 3 x Slot Horizontal |
| Connector Port (front) | 2 x USB |
| Indicators | LEDs for Power, 32 x HDD Activity, 3 x LAN, Fan Failure, Temperature Warning |
| Buttons | Power On/Off Momentary (Thin Rocker) Switch, System Reset |
| Crossbar | 2U Riser PCI Spanner Bar (for riser card) |
| Front Door(s) | Removable Single Door with 2 x Thumbscrew |
| Air Filter | Inside Front Panel (Washable) |
| Dimensions (W x H x D) | 483 (W) x 88 (H) x 526 (D) mm (19″ x 3.5″ x 20.1″) |
| Humidity | 5% – 95% Non-condensing |
| Product Applications | Standard Server Box, Decoder, Encoder |
